ASUS ROG Strix SCAR 17 G733PZ-LL002W 17.3" Gaming Laptop - AMD Ryzen 9 7945HX, RTX 4080, 32GB RAM, 1TB SSD, Wide Quad HD, Windows 11 Home, Black
ASUS ROG Strix SCAR 17 G733PZ-LL002W. Product type: Laptop, Form factor: Clamshell. Processor family: AMD Ryzen 9, Processor model: 7945HX, Processor frequency: 2.5 GHz. Display diagonal: 43.9 cm (17.3"), HD type: Wide Quad HD, Display resolution: 2560 x 1440 pixels. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: AMD Radeon 610M. Operating system installed: Windows 11 Home. Product colour: Black
ROG STRIX SCAR 17
Beat the best. Carve your legacy.
Reach the pinnacle of Windows 11 Pro gaming with the 2023 Strix SCAR 17, with up to an AMD Ryzen 9 7945HX CPU and up to an NVIDIA GeForce RTX 4090 Laptop GPU.
- Enjoy effortless Windows 11 Pro gaming performance with the Strix SCAR 17
- Up to an AMD Ryzen 9 7945HX 16-core processor with up to a 65W TDP
- Up to an NVIDIA GeForce RTX 4090 Laptop GPU with 175W max TGP, DLSS 3 and NVIDIA Advanced Optimus
- Conductonaut Extreme liquid metal and a custom vapor chamber keep the machine cool
- See a clear path to victory with QHD 240Hz display
- Dolby Vision HDR support and Spatial sound via Dolby Atmos bring your content to life
| Design |
|---|
| Market positioning | Gaming |
| Introduction year | 2023 |
| Form factor | Clamshell |
| Colour name | Off Black |
| Product colour | Black |
| Product type | Laptop |
| Display |
|---|
| High Dynamic Range (HDR) technology | Dolby Vision |
| High Dynamic Range (HDR) supported | Yes |
| Maximum refresh rate | 240 Hz |
| Display response rise/fall | 3 ms |
| Colour gamut | 100% |
| RGB colour space | DCI-P3 |
| Anti-glare screen | Yes |
| LED backlight | Yes |
| Native aspect ratio | 16:9 |
| Panel type | IPS |
| HD type | Wide Quad HD |
| Touchscreen | No |
| Display resolution | 2560 x 1440 pixels |
| Display diagonal | 43.9 cm (17.3") |
| Processor |
|---|
| Processor cache type | L2 & L3 |
| Processor cache | 80 MB |
| Processor cores | 16 |
| Processor boost frequency | 5.4 GHz |
| Processor frequency | 2.5 GHz |
| Processor model | 7945HX |
| Processor generation | AMD Ryzen 7000 Series |
| Processor family | AMD Ryzen 9 |
| Processor manufacturer | AMD |
| Memory |
|---|
| Maximum internal memory | 64 GB |
| Memory slots | 2x SO-DIMM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 4800 MHz |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 32 GB |
| Storage |
|---|
| Card reader integrated | No |
| Optical drive type | No |
| SSD form factor | M.2 |
| NVMe | Yes |
| SSD interface | PCI Express 4.0 |
| SSD capacity | 1 TB |
| Number of SSDs installed | 1 |
| Total SSDs capacity | 1 TB |
| Storage media | SSD |
| Total storage capacity | 1 TB |
| Graphics |
|---|
| NVIDIA G-SYNC | Yes |
| Discrete graphics memory type | GDDR6 |
| Discrete graphics card memory | 12 GB |
| On-board graphics card model | AMD Radeon 610M |
| On-board GPU manufacturer | AMD |
| Discrete graphics card model | NVIDIA GeForce RTX 4080 |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card | Yes |
| On-board graphics card | Yes |
| Audio |
|---|
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | Smart Amp |
| Camera |
|---|
| Front camera HD type | HD |
| Front camera | Yes |
| Network |
|---|
| Bluetooth version | 5.3 |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Ethernet LAN | Yes |
| Antenna type | 2x2 |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Mobile network connection | No |
| Bluetooth | Yes |
| Ports & interfaces |
|---|
| USB Power Delivery | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Power adapter barrel connector | 6.0 mm |
| Combo headphone/mic port | Yes |
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Keyboard |
|---|
| Keyboard backlit zone | Per-key RGB |
| Keyboard backlit colour | RGB |
| Keyboard backlit | Yes |
| Numeric keypad | Yes |
| Pointing device | Touchpad |
| Software |
|---|
| Trial software | 1-month trial for new Microsoft 365 customers |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Home |
| Battery |
|---|
| Battery capacity (Watt-hours) | 90 Wh |
| Number of battery cells | 4 |
| Battery technology | Lithium-Ion (Li-Ion) |
| Power |
|---|
| AC adapter output voltage | 20 V |
| AC adapter output current | 16.5 A |
| AC adapter input voltage | 100 - 240 V |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter power | 330 W |
| Security |
|---|
| Password protection type | BIOS, User |
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
| Weight & dimensions |
|---|
| Height (rear) | 2.83 cm |
| Height (front) | 2.34 cm |
| Depth | 282 mm |
| Width | 395 mm |
| Weight | 3 kg |
| General |
|---|
| Product family | ROG |
| Product series | Strix SCAR 17 |
